Urology

• Functional Length ~ 3cm provides superior surface contact
• Optimum location and design of grasping mechanism allows for full wrist articulation
• Cable flexibility reduces overall functional length to reach complex angles
• Flat array geometry combined with trapezoid imaging results in less surface pressure on organs while providing a very wide field of view
• Provides superior control and access during robot-assisted procedures
• Exceptional near and far-field resolution

Main Specifications:

• Array Type: Linear
• Frequency Range: 15 - 3 MHz
• Scan Width: 13 mm Radius

• Smaller profile provides greater control and access during robot-assisted procedures
• Optimum location and design of grasping mechanism allows for full wrist articulation
• Ideal for liver and kidney scanning
• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation

Main Specifications:

• Array Type: Linear
• Frequency Range: 12 - 2 MHz
• Scan Width: 26 mm

Curved array 4-way laparoscopic transducer for better visualization of targeted lesions.

• Built to withstand the rigors of daily laparoscopic surgery
• Ideal for liver and kidney scanning
• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation

Main Specifications:

• Array Type: Curved
• Frequency Range: 13 - 5 Mhz
• Insertion Diameter: 12 mm
• Scan Width: 40 mm Radius
• Scan Angle: 40 ° FOV

Exclusive linear array 4-way laparoscopic transducer for better visualization of targeted lesions.

• Built to withstand the rigors of daily laparoscopic surgery
• Ideal for liver and kidney scanning
• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation

Main Specifications:

• Array Type: Linear
• Frequency Range: 13 - 2 MHz
• Insertion Diameter: 10 mm
• Scan Width: 36 mm

Exclusive linear array rigid laparoscopic transducer for better visualization of targeted lesions.

• Built to withstand the rigors of daily laparoscopic surgery
• Preferred transducer for liver RFA and biopsies
• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation

Main Specifications:

• Array Type: Linear
• Frequency Range: 13 - 2 MHz
• Insertion Diameter: 10 mm
• Scan Width: 38 mm

Linear array side-fire “T” transducer for open surgical procedures.

• Smaller design for easy access
• Trapezoid imaging expands visibility
• Narrow field of view (42mm)
• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation
• Valuable information to guide tumor resections

Main Specifications:

• Array Type: Linear
• Frequency Range: 14 - 2 MHz
• Scan Width: 42 mm

Linear array side-fire “T” transducer for open surgical procedures.

• Wide field of view (63mm)
• PLUS Trapezoid imaging to further expand visibility
• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation
• Valuable information to guide tumor resections

Main Specifications:

• Array Type: Linear
• Frequency Range: 14 - 2 Mhz
• Scan Width: 63 mm

Curved array “T” style finger-grip transducer for open surgical procedures.

• Provides a transverse view in relation to the position of the transducer in the hand
• Designed to fit comfortably between the index and middle finger
• Allows for palpating organs and scanning at the same time
• Exceptional near and far field resolution
• Instant feedback on tumor margin delineation
• Valuable information to guide tumor resections

Main Specifications:

• Array Type: Curved
• Frequency Range: 10 - 3 Mhz
• Scan Width: 20 mm Radius
• Scan Angle: 65° FOV

Curved array deep penetration “I” style finger-grip transducer for open surgical procedures.

• Designed to fit comfortably between the index and middle finger
• Allows for palpating organs and scanning at the same time
• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation
• Valuable information to guide tumor resections

Main Specifications:

• Array Type: Curved
• Frequency Range: 6 - 1 Mhz
• Scan Width: 20 mm Radius
• Scan Angle: 82° FOV

Hockey-stick linear array transducer is the transducer of choice for cervical spine scanning.

• Exceptional near and far-field resolution
• Instant feedback on tumor margin delineation
• Valuable information to guide tumor resections
• Assistance in achieving complete tumor resection

Main Specifications:

• Array Type: Linear
• Frequency Range: 15 - 3 MHz
• Scan Width: 25 mm

Ideal transducer for Transperineal Biopsy, Hydrogel Spacer Placement, Brachy LDR & HDR, Cryo, and MPMRI procedures.

• Exclusive 64mm linear array accommodates even the largest gland
• Exclusive 200 degree FOV allows visualization of the entire gland
• Crystal dense array provides outstanding image quality

Main Specifications:

• Array Type: Convex / Linear
• Frequency Range: 8 - 4 / 10 - 5 MHz
• Scan Width: 10 / 64 mm
• Scan Angle: 200° FOV
• Trophon Compatible

Main Specifications:

• Sagital: 10 – 2 MHz | 200 FOV (10 mmR)
• Axial: 10 – 2 MHz  200 FOV (10 mmR)
• Simultaneous Display
• Wide Scanning
• Trophon Compatible

Main Specifications:

• Convex: 10 – 2 MHz | 200 FOV (9 mmR)
• Linear: 14 – 2 MHz | 63 mm
• Simultaneous bi-plane imaging
• Dual display format
• Trapezoidal display
• Trophon Compatible

Exclusive 200° FOV end-fire prostate biopsy transducer.

• Allows visualization of the entire gland from apex to base
• Crystal dense array provides outstanding image quality

Main Specifications:

• Array Type: Convex
• Frequency Range: 10 - 2 MHz
• Scan Width: 10mm Radius
• Scan Angle: 200º FOV
• Trophon Compatible

Provides real-time imaging of both the sagittal and transverse planes

• Simultaneous images provide visualization of the needle in both planes
• Enhanced visualization of needle entry and needle path for more confident biopsies
• Crystal dense array provides outstanding image quality

Main Specifications:

• Array Type: Convex / Linear
• Frequency Range: 8 - 4 / 8 - 4 MHz
• Scan Width: 10 / 10 mm
• Scan Angle: 120° FOV
• Trophon Compatible

38mm footprint is ideal for scrotal and penile doppler imaging

• Exceptional near and far field resolution
• Trapezoid Display - extends field of view and enables visualization of entire structure
• High Color Doppler sensitivity enhances visualization of superficial structures
• Enhances visualization of anatomy and needles perpendicular to the sound beam

Main Specifications:

• Array Type: Linear
• Frequency Range: 18 - 5 MHz
• Scan Width: 38 mm Width
• Smart Connector

Larger footprint is ideal for scrotal and penile doppler imaging

• Exceptional near and far field resolution
• Trapezoid Display - extends field of view and enables visualization of entire structure
• High Color Doppler sensitivity enhances visualization of superficial structures
• Oblique B-Mode Image
  • Utilize oblique angle views in B-mode to steer the beam not just CFI/CFA
  • Enhances visualization of anatomy and needles perpendicular to the sound beam

Main Specifications:

• Array Type: Linear
• Frequency Range: 13 - 5 MHz
• Scan Width: 50 mm

Designed for high-resolution imaging of the scrotal and penile regions. This advanced transducer offers exceptional image quality, user-friendly features, and specialized functionalities to support accurate urological diagnostics and enhance patient care.

• • Optimal frequency range, delivering superior resolution and clarity
• • Facilitates the accurate diagnosis of conditions such as testicular torsion, varicoceles, epididymal abnormalities, and penile structural issues
• • Ergonomic grip and lightweight construction
• • High Level Disinfection: Trophon & ASTRA VR Compatible
• • Sterilizable

Main Specifications:

• Array Type: Linear
• Frequency Range: 12 - 2 MHz
• Scan Width: 38 mm
